    Stainless Steel Vertical Pressure Leaf Filter For Crude Oil / Bleached Soil

    Ask Lasest Price
    Brand Name : Juneng Machinery
    Model Number : NYB
    Certification : CE、 ASME U、ISO9001
    Delivery Time : 10-30 days
    Payment Terms : TT
    Supply Ability : 40 set / months
    Price : 1000-20000 USD per set
    • Product Details
    • Company Profile

    Stainless Steel Vertical Pressure Leaf Filter For Crude Oil / Bleached Soil

    Low Cost Stainless Steel Vertical Pressure leaf filter for crude oil, bleached soil


    Product description:

    NYB high efficiency plate hermetic filter is a high-efficient, energy-saving and hermetically operated fine filter equipment. It is widely used in chemical, petroleum, painting, foodstuff, pharmaceutical and many other industries.
    The filter is composed of shell, filtration plate, cover, and automatic dump device.
    Among them, the filtration plate is made of many layers of stainless steel filtration
    materials, and they re installed on the central liquid collection pipe,
    so it can be dismantled for cleaning very conveniently.


    Application:

    Oil industry: crude oil, bleached oil, hydrided oil, radonized oil, stearin, fatty acid, etc.
    Petrochemical products: diesel oil, lubricating oil, paraffin and mineral moil products

    Organic chemical products: various organic acid, ester, benzene and aldehyde
    Oil paint: resin, varnish, dye and lacquer




    Product competitive advantage:

    Since this equipment has many advantages such as unique structure, compact volume, highfilter efficiency, fineness of filtered liquor, no material wastage, without consumption of filter paper, filter cloth. It’s only consuming small quantity of filter aid. It can be conveniently maintained, cleaned and operated at very low cost.


    Introduction of Company:

    Juneng Group employs a team of well-trained professional, adopts advance EPR production management model in cooperation with state–of–the–art apparatus and process i.e. CNC Turner, Machine Center, Highly Accuracy Test Instrumentation, Quality and Process Control System to ensure quality, stability, and reliability of every product.




    Product Specifications:



    Outline form & assembly size :

    ModelShell diameterSpace between filter leafInlet/outlet caliberOverflow portDischarge portHeightFloor Spare
    NYB-2∅40050DN25DN25DN1501550620×600
    NYB-4∅50050DN40DN25DN2001800770×740
    NYB-7∅60050DN40DN25DN25022001310×1000
    NYB-10∅80070DN50DN25DN30024001510×1060
    NYB-12∅90070DN50DN40DN40025001610×1250
    NYB-15∅100070DN50DN40DN40026501710×1350
    NYB-20∅100070DN50DN40DN40029501710×1350
    NYB-25∅110070DN50DN40DN50030201810×1430
    NYB-30∅120070DN50DN40DN50031502030×1550
    NYB-36∅120070DN65DN50DN50032502030×1550
    NYB-40∅130070DN65DN50DN60033502130×1560
    NYB-45∅130070DN65DN50DN60035502130×1560
    NYB-52∅140075DN80DN50DN60036702230×1650
    NYB-60∅150075DN80DN50DN60038102310×1750
    NYB-70∅160080DN80DN50DN60045003050×1950
    NYB-80∅175080DN80DN50DN60045003210×2100
    NYB-90∅185080DN80DN50DN60046503300×2200
