    Hermetic Operating Horizontal Plate Pressure Filter Carbon Steel Material Color Customized

    Ask Lasest Price
    Brand Name : Juneng Machinery
    Model Number : SZL
    Certification : CE、 ASME U
    Price : $ 10,000-200,000 / set
    Payment Terms : TT
    Supply Ability : 40 set / months
    Delivery Time : 60 days
    • Product Details
    • Company Profile

    Hermetic Operating Horizontal Plate Pressure Filter Carbon Steel Material Color Customized


    Solid-liquid Separating Hermetic Operating Vertical Pressure Leaf Filter for Petroleum

    Product competitive advantage:


    1, Completely enclosed filtration, no leakage, no pollution.


    2, Once filtering complete clarifed, it filtering precision up to PPM.


    3, Less cost of production, and easy to repair and maintain.


    Product Description:


    SZL series horizontal paper plate filter is a solid-liquid separating equipment with characteristics as high-efficiency, energy-saving, hermetic operating. It is mainly used in refine filtration of the liquid. We can get filtrate with different precision through choosing filtering paper.

    The filter is composed of tank, layers of horizontal filter plates and filter paper which is installed between filter discs. Filter paper is used as filter medium to pressed filter in hermetic tank.



    During filtering, filtrate is conveyed to filter tank by pump and gets into middle of two filter plates from hole which are around the filter plates.

    Filtrate comes into hole of filter plate through filter paper and support plates, and comes out from the bottom. After filter finished using compressed air to press the residual liquid out.


    Product Applications:


    SZL series horizontal paper plate filter is a solid-liquid separating equipment with characteristics as high-efficiency, energy-saving, hermetic operating. It is widely used in chemical, petroleum, foodstuff, oils and fats, pharmacy, etc.




    Product Specifications:


    Model

    Filtration
    area (㎡)

    Treatment
    capacity (T/H)

    Working
    pressure (Mpa)

    Working
    temperature(℃)

    Inlet/outlet
    nozzle (mm)

    Shell
    diameter (mm)

    SZL-1.5

    1.5

    2

    ≤0.3

    ≤150

    DN50

    400

    SZL-3

    3

    4

    DN50

    600

    SZL-5

    5

    7

    DN50

    800

    SZL-7

    7

    10

    DN50

    800

    SZL-10

    10

    13

    DN50

    900

    SZL-12

    12

    15

    DN50

    900

    SZL-15

    15

    18

    DN50

    900



    Company detail

    The Company now has its three production bases with a total capacity of 280,000 square meters in Nanjing city and Yixing City , permanent workforces not less than 1100 people and the production line is well equipped with more than 2000 inits of advanced production equipment and test Instrumentation


    After service :


    1. Months guarantee period from machine arriving date.


    2. Sufficient spare parts in stock are available.

    3. Routine tracing will be done timely.


    4. Guide you do the normal maintenance.
