Food Standard Stainless Steel Disc Oil Centrifuge Separator Used
for Vegetable Oil
Product description:
The principle of using light, heavy, or solid phases with different
densities and immiscibility in a mixed liquid (erosion solution) to
undergo different centrifugal forces in a centrifugal force field,
resulting in different settling velocities, achieves the goal of
separating and layering or settling solid particles in the liquid.
The separated mixed oil is smoothly and evenly fed into the drum of
the heart part of the machine. Under the strong centrifugal force
field generated by high-speed operation, the mixed oil passes
through a separation interval of a set of disc bundles, with the
neutral hole of the disc as the interface. Heavy phases (such as
phospholipids, soap feet, etc.) with a larger proportion move along
the disc wall towards the outside of the neutral hole, where heavy
residues (such as oil sludge) accumulate in the sediment area and
are automatically discharged from the machine during the cycle.
The light phase with a smaller specific gravity (such as grease)
moves upwards along the disc wall to the top of the drum, and is
pumped from the light phase towards the center to the next process.
The heavy phase is discharged by the heavy phase towards the center
pump. The working diameter of the heavy phase centripetal pump can
be adjusted, and changes in its size can change the interface
between the light and heavy phases in the drum, achieving different
separation effects.
Application:
DHZ series disc centrifuge for vegetable oil refining are widely
used in continuous degumming, neutralizing, dewaxing, and washing
of vegetable oils .
Vegetable oil: Colza oil, cottonseed oil, Corn oil, palm oil, soybean oil, Peanut
oil, Rice oil, Sesame oil, Safflower oil and son on.
Animal oil: fish oil and other various animal fat clarification.
Product Specifications:
| Model | Treatment capacity (L/H) | Inlet Pressure (Mpa) | Outlet pressure (Mpa) | Motor power (Kw) | Weight (Kg) | Outline dimension (mm) | | DHZ360 | 1200-2500 | 0.05 | 0.1-0.25 | 7.5 | 1280 | 1500*1150*1500 | | DHZ470 | 2500-7000 | 0.05 | 0.1-0.25 | 15 | 1880 | 1800*1200*1800 | | DHZ550A | 5000-10000 | 0.05 | 0.1-0.25 | 18.5 | 2200 | 1850*1550*2050 | | DHZ550E | 6000-15000 | 0.05 | 0.1-0.25 | 22 | 2200 | 1850*1550*2050 | | DHZ700 | 15000-30000 | 0.1 | 0.2 | 30 | 3300 | 2100*1650*2300 | | DRZ360 | 1200-2500 | 0.05 | 0.1-0.25 | 5.5 | 750 | 1250*1050*1500 | | DRZ400A | 2000-6000 | 0.05 | 0.1-0.3 | 7.5 | 1150 | 1300*900*1450 | | DRZ400E | 4000-7500 | 0.05 | 0.1-0.3 | 7.5 | 1300 | 1300*900*1500 | | DRZ550 | 6000-18000 | 0.05 | 0.1-0.3 | 22 | 2200 | 1620*1300*2200 |
|
Product competitive advantage:
1, The professional designed centripetal pump system has many
advantages such as stability outlet pressure, large regulating
sphere, easily operating and so on.
2, This special design separator has the full automatic control box
which used for safety protection and equips and also been equipped
with advanced automatic vibration tester which can view vibrating
value at any time. We can make separating and discharging to the
best affection from regulating separation parameter directly at the
screen.
