Fine Separating Affection Disc Oil Centrifuge Separator Used for
Animal Fat Clarification
Product description:
Juneng Separator can suitable for a variety of oils and fats and
provide personalized solutions in order to achieve optimal oil and
maximized production capacity
DHZ series disc centrifuge for vegetable oil refining are widely
used in continuous degumming, neutralizing, dewaxing, and washing
of vegetable oils .
Centripetal pump system designed by our proffessional designer has
the traits as stability outlet preaaure,large regulating sphere and
operating easily.
Introduction of Company:
Juneng Group employs a team of well-trained professional, adopts
advance EPR production management model in cooperation with
state–of–the–art apparatus and process i.e. CNC Turner, Machine
Center, Highly Accuracy Test Instrumentation, Quality and Process
Control System to ensure quality, stability, and reliability of
every product.
Application:
DHZ series disc centrifuge for vegetable oil refining are widely
used in continuous degumming, neutralizing, dewaxing, and washing
of vegetable oils .
Vegetable oil: Colza oil, cottonseed oil, Corn oil, palm oil, soybean oil, Peanut
oil, Rice oil, Sesame oil, Safflower oil and son on.
Animal oil: fish oil and other various animal fat clarification.
Product competitive advantage:
1, High rotating speed
2, Lower noise
3, The professional designed centripetal pump system has many
advantages such as stability outlet pressure, large regulating
sphere, easily operating and so on.
4, This special design separator has the full automatic control box
which used for safety protection and equips and also been equipped
with advanced automatic vibration tester which can view vibrating
value at any time. We can make separating and discharging to the
best affection from regulating separation parameter directly at the
screen.
Product Specifications:
| Model | Treatment capacity (L/H) | Inlet Pressure (Mpa) | Outlet pressure (Mpa) | Motor power (Kw) | Weight (Kg) | Outline dimension (mm) | | DHZ360 | 1200-2500 | 0.05 | 0.1-0.25 | 7.5 | 1280 | 1500*1150*1500 | | DHZ470 | 2500-7000 | 0.05 | 0.1-0.25 | 15 | 1880 | 1800*1200*1800 | | DHZ550A | 5000-10000 | 0.05 | 0.1-0.25 | 18.5 | 2200 | 1850*1550*2050 | | DHZ550E | 6000-15000 | 0.05 | 0.1-0.25 | 22 | 2200 | 1850*1550*2050 | | DHZ700 | 15000-30000 | 0.1 | 0.2 | 30 | 3300 | 2100*1650*2300 | | DRZ360 | 1200-2500 | 0.05 | 0.1-0.25 | 5.5 | 750 | 1250*1050*1500 | | DRZ400A | 2000-6000 | 0.05 | 0.1-0.3 | 7.5 | 1150 | 1300*900*1450 | | DRZ400E | 4000-7500 | 0.05 | 0.1-0.3 | 7.5 | 1300 | 1300*900*1500 | | DRZ550 | 6000-18000 | 0.05 | 0.1-0.3 | 22 | 2200 | 1620*1300*2200 |
|
Operational Tenets:
Strategy: Being professional and devoted to build up core competitiveness
Market: European quality, Chinese price
Mangement: practical, standard and successive improvement
Service: honest, responsable and timely
Talent: merits, cooperation and caring
Technology: technology leadership
