Efficiency Disc Oil Separator Centrifuge Automatic Discharge for
Fish oil / Animal oil
Application:
DHZ series disc centrifuge for vegetable oil refining are widely
used in continuous degumming, neutralizing, dewaxing, and washing
of vegetable oils .
Vegetable oil: Colza oil, cottonseed oil, Corn oil, palm oil, soybean oil,
Peanut oil, Rice oil, Sesame oil, Safflower oil and son on.
Animal oil: fish oil and other various animal fat clarification.
DHZ series comes complete with control unit, electric motor, inlet
and outlet connections, auxiliary equipment, spare parts and a set
of tools
Technologic parameters:
| Model | Treatment capacity L/H | Inlet pressure MPa | Outlet pressure MPa | Motor power Kw | Weight Kg | Outline dimension mm |
| DHZ360 | 1200-2500 | 0.05 | 0.1-0.25 | 7.5 | 1280 | 1500*1150*1500 |
Product competitive advantage:
1, High rotating speed
2, Operating stability
3, Completely sealed up of the inlet and outlet system
4, Lower noise
5, The professional designed centripetal pump system has many
advantages such as stability outlet pressure, large regulating
sphere, easily operating and so on.
6, This special design separator has the full automatic control box
which used for safety protection and equips and also been equipped
with advanced automatic vibration tester which can view vibrating
value at any time. We can make separating and discharging to the
best affection from regulating separation parameter directly at the
screen.
Details:
- Capacity : 1000-100,000 L/H
- Condition: New
- Type: disc centrifuge
- Automatic Grade: Automatic
- Place of Origin: China (Mainland)
- Brand Name: JUNENG
- Voltage: 380-415V
- Power(W): 7.5- 22 Kw
- Weight: 1000-3000KG
- Certification: CE/ISO
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service
machinery overseas
- Type: Meat Processing Machinery
- Bowl: self-cleaning
- Wet material: stainless steel
- PLC: SIEMENS
Product description:
Mainly used in the system of vegetable oil for consecutive
degumming, and dehydration.
This type of disc centrifuge is mainly used in the system of
vegetable oil for consecutive degumming, and dehydration, which is
the major equipment for 10t/d~400t/d.It also works in refining meat
oil from animals, or in concentrating separation of fish oil.
It has advantages of high speed, smooth operating, compact
structure, small footprint, all sealed of the inlet and discharge,
little noise, good separation. The materials of centrifuge which
contact with the parts are manufactured by stainless steel which
meets the requirements of food hygiene.
This product has three types, including central value deslagging,
artificial deslagging, and water push deslagging. The first type is
mainly used in the desoponificating of oil refining, and the last
two are used in degumming and dehydrating.
Moreover they are all applicable to other similar materials for
liquid-liquid-solid and liquid –solid separation.
The design, manufacture and inspection of centrifuge are accordance
with the national standards GB10897 and GB10898 strictly.
This type of disc centrifuge is mainly used to remove the water and
mechanical impurities contained in equipment fuel and lubricants in
boating mainframe, diesel power station as well as other types of
mineral oil, in order to reduce diesel engine or other mechanical
wear and extend the useful life of the mechanical.
Also applies to separate and clarify similar materials of waste oil
in other petrochemical industries, such as black oil, delayed
coking oil coking oil, washing oil and recycle oil and so on.
The design, manufacture and inspection of centrifuge are accordance
with the national standards GB10897 and GB10898 strictly.
