    Orange Juice Decanter Centrifuge Mahine VFD 350 Mm 22 Kw

    Ask Lasest Price
    Brand Name : Juneng Machinery
    Model Number : LW350
    Certification : CE
    Price : $ 38,000-42,000 / set
    Payment Terms : TT, L/C
    Supply Ability : 10 set / months
    Delivery Time : 70 Days
    • Product Details
    • Company Profile

    Orange Juice Decanter Centrifuge Mahine VFD 350 Mm 22 Kw

    Juneng Brand Long Service Life VFD Orange Juice Decanter Centifuge Mahine


    Description


    The Decanter Centrifuge
    When it comes to separating solid/liquid mixes with a high solids content, decanter centrifuges are the way to go. These solid-shell scroll centrifuges or decanters, unlike chamber filter presses, run continuously. The finely distributed solid particles are separated from the suspension by strong centrifugal forces.

    Decanters are useful in a wide variety of industries throughout the world. The centrifuges are optimally adapted for the specific application. Applications range from sludge dewatering to classification or wet classification to the sorting of solids.

    To obtain optimum results, solid bowl decanter centrifuges must be custom designed to suit specific separation processes.


    The process of fresh fruit juicing is to transform the solid pulp into liquid liquid suspension of turbid fruit and vegetable juice. Note that although fruit and vegetable juice allows a part of precipitation, it is still suspension on the whole, in order to give users the best experience in vision and taste. This results in the need of filtering part of the fruit residue to concentrate juice. The use of centrifuge equipment such as horizontal screw centrifuge instead of the traditional filtration way to separate solid and liquid not only improves the efficiency, but also improves the quality.


    The application of horizontal screw centrifuge in the fresh juice industry mainly has two aspects, one is used for solid-liquid separation in the juicing process to improve the quality, and the other is for environmental protection of wastewater treatment. It is directly involved in the production of horizontal screw centrifuge for the solid-liquid separation of juice. As mentioned above, the centrifuge equipment replaces the traditional filtration equipment such as plate frame press filter and press cloth dump bucket, which not only has high efficiency, but also has the advantages of adjustable filtration precision. It is especially suitable for the special demand of adjustable precision parameters of the fruit slag concentration in the packaging of fresh juice, which has the advantages that traditional filtration equipment does not have


    As for the application of wastewater treatment centrifuge in juice beverage industry, juice beverage industry is also an industrial production field, which not only meets the characteristics of industrial wastewater with high pollutant content and difficult wastewater treatment, but also has the characteristics of industrial wastewater with high concentration of organic matter and fast deterioration and strong smell. The pollution caused by wastewater discharge in juice industry has become a prominent problem. Centrifuge and other new technology and equipment on the horse treatment of juice industry wastewater has become an urgent need.


    Specification


    Model

    Drum diameter

    mm

    Draw Ratio

    L/D

    Speed of drum

    r/min

    Factor of separation G

    Spiral difference rotate speed

    r/min

    Inlet capacity(m3/h)

    Main/assist motor (KW)

    LW350

    350

    4.1

    3600

    3133

    2~26

    5~15

    22/5.5


    Application


    This Decanter centrifuge is most often used for clarification of liquid containing high concentrations of solid, removing solids from liquid. This model is special used for purification of juice and dehydration of fruit fiber .



    Certifications:


    After service :

    1. Months guarantee period from machine arriving date.


    2. 24 hours technical consultation


    3. Guide you do the normal maintenance.


    4. Markting team will visiting if you need


    QA/QC Department


    1.Factory visit/ audit is required prior to other purchase


    2.Inspection of material is required during in process manufacturing & prior shipment


    3.Compliance to technical requirements


    Operational Tenets of Juneng Group:


    Strategy: Being professional and devoted to build up core competitiveness


    Market: European quality, Chinese price


    Mangement: practical, standard and successive improvement


    Service: honest, responsable and timely


    Talent: merits, cooperation and caring


    Technology: technology leadership
