Juneng Brand Long Service Life VFD Orange Juice Decanter Centifuge
Mahine
Description
The Decanter Centrifuge
When it comes to separating solid/liquid mixes with a high solids
content, decanter centrifuges are the way to go. These solid-shell
scroll centrifuges or decanters, unlike chamber filter presses, run
continuously. The finely distributed solid particles are separated
from the suspension by strong centrifugal forces.
Decanters are useful in a wide variety of industries throughout the
world. The centrifuges are optimally adapted for the specific
application. Applications range from sludge dewatering to
classification or wet classification to the sorting of solids.
To obtain optimum results, solid bowl decanter centrifuges must be
custom designed to suit specific separation processes.
The process of fresh fruit juicing is to transform the solid pulp
into liquid liquid suspension of turbid fruit and vegetable juice.
Note that although fruit and vegetable juice allows a part of
precipitation, it is still suspension on the whole, in order to
give users the best experience in vision and taste. This results in
the need of filtering part of the fruit residue to concentrate
juice. The use of centrifuge equipment such as horizontal screw
centrifuge instead of the traditional filtration way to separate
solid and liquid not only improves the efficiency, but also
improves the quality.
The application of horizontal screw centrifuge in the fresh juice
industry mainly has two aspects, one is used for solid-liquid
separation in the juicing process to improve the quality, and the
other is for environmental protection of wastewater treatment. It
is directly involved in the production of horizontal screw
centrifuge for the solid-liquid separation of juice. As mentioned
above, the centrifuge equipment replaces the traditional filtration
equipment such as plate frame press filter and press cloth dump
bucket, which not only has high efficiency, but also has the
advantages of adjustable filtration precision. It is especially
suitable for the special demand of adjustable precision parameters
of the fruit slag concentration in the packaging of fresh juice,
which has the advantages that traditional filtration equipment does
not have
As for the application of wastewater treatment centrifuge in juice
beverage industry, juice beverage industry is also an industrial
production field, which not only meets the characteristics of
industrial wastewater with high pollutant content and difficult
wastewater treatment, but also has the characteristics of
industrial wastewater with high concentration of organic matter and
fast deterioration and strong smell. The pollution caused by
wastewater discharge in juice industry has become a prominent
problem. Centrifuge and other new technology and equipment on the
horse treatment of juice industry wastewater has become an urgent
need.
Specification
Model | Drum diameter mm | Draw Ratio L/D | Speed of drum r/min | Factor of separation G | Spiral difference rotate speed r/min | Inlet capacity(m3/h) | Main/assist motor (KW) |
LW350 | 350 | 4.1 | 3600 | 3133 | 2~26 | 5~15 | 22/5.5 |
Application
This Decanter centrifuge is most often used for clarification of
liquid containing high concentrations of solid, removing solids
from liquid. This model is special used for purification of juice
and dehydration of fruit fiber .
Certifications:
After service :
1. Months guarantee period from machine arriving date.
2. 24 hours technical consultation
3. Guide you do the normal maintenance.
4. Markting team will visiting if you need
QA/QC Department
1.Factory visit/ audit is required prior to other purchase
2.Inspection of material is required during in process
manufacturing & prior shipment
3.Compliance to technical requirements
