LW450W Oil Field Watertreatment Sludge Dewatering Decanter
Centrifuge Machine
Product description:
You can comprehensively consider factors such as the physical
properties, separation requirements, processing capacity, and
process requirements of the separated material (suspension).
Reasonably selecting the working parameters of the centrifuge can
achieve satisfactory separation results and economic benefits.
In the material, larger solid particles easier separated, when the
size of solid particles not the same, so small particle solid phase
decides the final separating effect This equipment can remove the
solid particle which is over than 5um, if the solid phase particles
is very small, so it can’t be separated through settlement and it
will be discharged together with clear liquid, so the final
separating effect is depend on the distribution of solid phase
particle. Too much particles’ size over 5um , the separating effect
is more better, on the other hand the separating effect maybe more
worse .
| Model | Drum diameter
mm | Draw Ratio
L/D | Speed of drum
r/min | Factor of
separation G | Spiral difference
rotate speed
r/min | Inlet
capacity(m3/h) | Main/assist
motor (KW) |
| LW250W | 250 | 3.73 | 4200 | 2467 | 2~31 | 1-7 | 11/4 |
| LW350W | 350 | 4.4 | 3600 | 2540 | 5~25 | 5~18 | 22/5.5 |
| LW450W | 450 | 4.4 | 3200 | 2580 | 5~25 | 5~28 | 30/11 |
| LW520W | 520 | 4.1 | 2850 | 2365 | 2~26 | 10~35 | 45/11 |
| LW550W | 550 | 4.1 | 2650 | 2370 | 2~26 | 10~45 | 55/11 |
Application:
Decanter centrifuge is most often used for clarification of liquid
containing high concentrations of solid, removing solids from
liquid. It is usually used in waste water and PVC sludge industry.
And also can be used in sunflower oil, palm oil and tea industry.
Discharged sludge almostly dry
Product competitive advantage:
1, Helical pusher adopts the special antifriction method: sprinkle
hardness alloy or inlay hardness alloy anti-friction disk; anti
–corrosion stainless steel is employed for the material of the main
parts of drum, so that assure the durability and longer using
lifetime of the equipment.
2, According to the operating condition’s characteristics of
material, optimize the drum length-diameter raido, drum and
structure of drum taper parts.
Introduction of Company:
Juneng Group employs a team of well-trained professional, adopts
advance EPR production management model in cooperation with
state–of–the–art apparatus and process i.e. CNC Turner, Machine
Center, Highly Accuracy Test Instrumentation, Quality and Process
Control System to ensure quality, stability, and reliability of
every product.
Juneng’s success is contributed by the commitment of every member
of the Company. In addition, the specialty and potential of each
member is being respected and disinterred.
Delivery
| Packaging | Seaworthy wooden case |
| Transportation | Automobile transport to shipping port |
