Energy Efficient Centrifugal Separator For Dewaxing Processing Batch Filtration
Overview
Horizontal Pressure Leaf Filters from Huading Separator are special
designed for semi-automatic or fully automatic models for fast,
efficient, liquid-solid separation. The Horizontal Pressure Leaf
Filter is ideally suited for high and / or constant flow, batch
filtration, with dry cake or wet cake discharge options.
Work principle
When filtering, the filter aid is mixed with the material in the
mixing cylinder, and a filter cake layer is formed on the filter
screen through a transport pump. Once a stable filter cake layer is
reached, the small filter aid particles provide countless fine
channels to trap suspended impurities and allow clear liquid to
pass through. This way, the material is actually filtered through
the cake layer.
When the filter residue on the surface of the filter plate reaches
a certain thickness or the filtration pressure reaches 0.4MPa, stop
feeding, blow dry the filter cake with compressed air or steam,
clean the filter screen and discharge the residue. The filter
residue is unloaded due to gravity and vibration. For viscous
filter cakes, manual assistance is required to clean the residue.
Specifications:
| Product Name | Area series ( ㎡) | Shell diameter series ( mm) | Work pressure ( Mpa) | Work temperature
(℃) | Proximate treatment
capacity (T/H·㎡) |
| Energy Efficient Centrifugal Separator For Milk Processing Batch
Filtration | 5, 10, 15, 20, 25, 30, 35, 40,
45, 50, 60, 70, 80, 90, 100, 120,
140, 160, 180, 200 | 900, 1200, 1400, 1500, 1600,
1700, 1800, 2000 | 0.4
| 150
| Oil | 0.2 |
| Beverage | 0.8 |
Application:
Food industry : Syrups, edible oils, dewaxing , decolour, degrease
Chemical industries: Sulphur, aluminum sulfate, Polyaluminum
chloride, plastic, dyestuff intermediate, bleaching liquid,
lubricant additives and intermediate and high pressure
polyethylene, etc.
Introduction of Company:
Juneng Group is a large scale manufacturer, we have four factories which located in Nanjing and Yixing City with
convenient transportation access.
The company is proud to be the leader in such industry with 80%
domestic market share in Oils & Fats industry,Chemical industry,
Pharmaceutical industry, Beverage industry, Petrol-chemical
industry, and now is one of the well-known producers and suppliers
in the world. Our products are also exported to clients in such
countries and regions as USA,German, Korea,Japan, Pakistan,
Malaysia, Singapore, Vietnam and so on.
