Stainless Steel Centrifugal Filter Separator For Fruits And
Vegetables
Centrifugal Filter Separator Working Principle
The motor actuates the bowl to rotate around spindle through
transmission system. The separated suspension liquid enters into
bowl through the feed pipe on top, and falls on the material
distribution tray. Under the function of centrifugal force, it
flows to the wall of bowl, and the liquid phase is thrown into the
space of machine cabinet through gauze and filter opening on the
wall of bowl and collected on the under pan, to be discharged via
liquid drain pipe, while the solid phase is retained on the inner
side of the filter gauze. If rinse is required, washing water is to
be added for rinse through washing pipe. After dehydration is
completed, the bowl will stop, then the solid-phase substances will
be discharged manually.
Centrifugal Filter Separator Application
1. General Fruits and vegetables: tomato juice, carrot juice,
lycopene, apple juice, lemon juice, citrus juice.
2. Tropical fruits: passion fruit, mango, pineapple, guava, papaya,
etc.
3. Vegetable juice: celery, lettuce, cucumber, onion, garlic,
spinach, etc.
4. Various wines, wort
Centrifugal Filter Separator advantage:
High speed, stable operation, fully closed of inlet and outlet
system, low noise, good separation, high oil rate, fully automatic
control , easy to operate.
Centrifugal Filter Separator Specifications:
Model | Treatment
capacity (L/H) | Inlet
pressure (Mpa) | Outlet
pressure (Mpa) | Motor
power (Kw) | Weight(Kg) | Outline
dimension (mm) |
DHFX211 | 2-5 | 0.1 | 0.4 | 15 | 1600 | 1700*1200*1720
|
| DHFX214 | 4-9 | 0.2 | 0.4 | 22 | 2300 | 1980*1610*1950 |
Introduction of Company:
Juneng Group employs a team of well-trained professional, adopts
advance EPR production management model in cooperation with
state–of–the–art apparatus and process i.e. CNC Turner, Machine
Center, Highly Accuracy Test Instrumentation, Quality and Process
Control System to ensure quality, stability, and reliability of
every product.
Why Choose Juneng brand
1. International High quality Certification production chain .
2. Manufacturer, more reasonable price .
3. Solid technical support and after-sales service
