High Efficiency Industrial Bag Filters For Paint , Beer , Vegetable
Oil
Industrial Bag Filters Introduction
Filter body is mainly composed of three parts:the filter
container,supporting basket and the filter bag,filter process.
Replace or clean the filter bag,just loosen the ring bolt,rotating
the hand-wheel lifting cover,can be removed.
Multi bag filter has the characteristics of large capacity,large
amount of contamination,obvious filtration effect,simple
poeration,low cost operation.
Industrial Bag Filters Description:
DL series bag filter is a multifunction filter equipment with new
structure, small occupancy, flexible operation, energy-saving,
high-efficiency, enclosed operation and excellent applicability.
DL series filter bag is mainly composed by filter cylinder,
cylinder lid, quick-opening structure, filter bag reinforce net.
DL series filter bag belongs to pressure filter equipment , liquid
flow into the filter bag through the side-way. Filter bag itself is
fitted in the reinforce net that the qualified filtrate is achieved
after the liquid pass the filter bag which has various precision
ranks.
The impurity is seized by the filter bag. The filter bag is easy to
be changed and has little consumption of materials.
Industrial Bag Filters Applications:
It’s widely used in paint, beer, vegetable oil, pharmaceutical,
cosmetic, chemicals, petroleum products, textile chemicals,
sensitization chemical, electroplate, milk, mineral water, hot
solvent, milk rubber, industrial water, sweet water, resin,
printing ink, industrial waste water, juice, edible oil, etc.
Industrial Bag Filters Specifications:
| Model | Filtration area ㎡ | Inlet/outlet caliber mm | Max flowrate ㎥/h | Max work pressure Mpa | Max temperature ℃ | Nominal filtration precision μm |
| DL-1P1S | 0.25 | DN40 | 10 | 0.4 | 120The working temperature is related to the material of filter bag
. | 1,5,10,15,25,40,50,65,75,80,100……1200 |
| DL-1P2S | 0.5 | DN40 | 20 |
| DL-4P2S | 2 | DN80 | 80 |
| DL-8P2S | 4 | DN125 | 160 |
| DL32P2S | 16 | DN200 | 640 |
