Compact Structure Centrifugal Oil Water Separator For Liquid -
Liquid - Solid Separation
Centrifugal Oil Water Separator Operation Principe
Separation takes place inside a rotating bowl. The feed is
introduced to the rotating centrifuge bowl from the top via a
stationary inlet pipe (1),and is accelerated in the
distributor(2),which was specially designed to ensure smooth
acceleration of the feed liquid(4). Leaving the distributor, the
feed enters the disc stack(3). The separation into
liquid-liquid-solid takes place between the discs, with the oil
phase moving through the disc stack to the centre. When it reaches
the centre, it is discharged through hole (5) and ejected into the
collecting frame. The water and heavy solid separated from the oil
move to the periphery, and the water flows via channels in the top
disc(6) to the paring chamber, where it is pumped out of the rotor
by means of a built-in paring disc(7).During purification, hot
water is fed into the inlet of the bowl before the process liquid
is introduced. The water forms a seal around the outer edge of the
top disc. The solid collect in the periphery where they are
discharged intermittently via the centrifuge cyclone. The solid are
discharged by means of a hydraulic system, which forces the sliding
bowl bottom(8)to drop down at preset suitable intervals, thus
opening the solid ports at the bowl periphery
Centrifugal Oil Water Separator Features:
1. High speed
2. Stable operation
3.Fully closed of inlet and outlet system
4. Low noise
5. Fine separation
Centrifugal Oil Water Separator Specifications:
| Model | Rated Treatment
capacity (L/h) | Inlet pressure (Mpa) | Outlet
pressure (Mpa) | Suck Journey
of Sump Pump | Outlet pressure
of sump pump | Motor (KW) |
| KYDB204 | 2000 | ≤0.05 | ≥0.2 | / | / | 4 |
Centrifugal Oil Water Separator advantage:
1. This series of separator outfits various specific gravity rings
with different diameter, which can be selected and used according
to the density and volume of the materials.
2. It has backpressure regulating valve. Separating effect can be
regulated by regulating backpressure.
History of Juneng :
Juneng Group was established at 1987. It has 31- year history. Now
its three production bases with a total capacity of 280000 square
meters in Nanjing City and Yixing City of Jiangsu Province.
Juneng’s success is contributed by the commitment of every member
of the Company. In addition, the specialty and potential of each
member is being respected and disinterred.
Track Records of Juneng:
1. With the outstanding track records, our products are widely
applied into different industries
2. The key factors of our success are to constantly fulfilling
customer's requirement and exceed their ecpection.
3.We are loking forward to your guidance, opinion and suggestions
that would be a long term mutual beneficially business
relationship.
