Bowl Type Industrial Oil Separator Machine For Vegetable Oil
Refining
Disc Oil Separator Description:
The machine consists of a frame that has a horizontal drive shaft
with clutch and brake, worm gear , lubricating oil bath and
vertical bowl spindle in the lower part.
The bowl is mounted on top of the spindle in the lower part. The
bowl is mounted on top of the spindle , inside the space formed by
the upper parts of the frame , the ring solid cover, the collecting
cover, and frame hood . The feed and liquid discharge system ,
including the paring disc pump for the heavy phase, also rests on
this structure. All parts in contact with the process liquid are
made of stainless steel. The bowl is of the solid-ejecting disc
type with hydraulic operating system. The electric motor is of the
variable frequency drive type or of controlled-torque type.
Application:
DHZ series disc centrifuge for vegetable oil refining are widely
used in continuous degumming, neutralizing, dewaxing, and washing
of vegetable oils .
Vegetable oil: Colza oil, Cottonseed oil, Corn oil, Palm oil, Soybean oil, Peanut
oil, Sunflower oil, Rice oil, Sesame oil, Safflower oil and son on.
Animal oil: fish oil and other various animal fat clarification.
Product competitive advantage:
1, High rotating speed
2, Lower noise
3, The professional designed centripetal pump system has many
advantages such as stability outlet pressure, large regulating
sphere, easily operating and so on.
Product Specifications:
| Model | Treatment capacity (L/H) | Inlet Pressure (Mpa) | Outlet pressure (Mpa) | Motor power (Kw) | Weight (Kg) | Outline dimension (mm) | | DHZ360 | 1200-2500 | 0.05 | 0.1-0.25 | 7.5 | 1280 | 1500*1150*1500 | | DHZ470 | 2500-7000 | 0.05 | 0.1-0.25 | 15 | 1880 | 1800*1200*1800 | | DHZ550A | 5000-10000 | 0.05 | 0.1-0.25 | 18.5 | 2200 | 1850*1550*2050 | | DHZ550E | 6000-15000 | 0.05 | 0.1-0.25 | 22 | 2200 | 1850*1550*2050 | | DHZ700 | 15000-30000 | 0.1 | 0.2 | 30 | 3300 | 2100*1650*2300 | | DRZ360 | 1200-2500 | 0.05 | 0.1-0.25 | 5.5 | 750 | 1250*1050*1500 | | DRZ400A | 2000-6000 | 0.05 | 0.1-0.3 | 7.5 | 1150 | 1300*900*1450 | | DRZ400E | 4000-7500 | 0.05 | 0.1-0.3 | 7.5 | 1300 | 1300*900*1500 | | DRZ550 | 6000-18000 | 0.05 | 0.1-0.3 | 22 | 2200 | 1620*1300*2200 |
|
Introduction of Company:
Juneng Group employs a team of well-trained professional, adopts
advance EPR production management model in cooperation with
state–of–the–art apparatus and process i.e. CNC Turner, Machine
Center, Highly Accuracy Test Instrumentation, Quality and Process
Control System to ensure quality, stability, and reliability of
every product.
